5
PRODUCT OVERVIEW
1. Case
2. LCD
3. Function keys
4. Rotary switch
5. Input terminals
Function Description
1. Label of function keys
Indicates auxiliary functions under current measuring
interface.
2. Simulation bar Analogue display of input signals.
3. Minus sign Indicates negative reading.
4. Lighting symbol Danger - High voltage.
5. Time and date Indicates the time and date set in internal clock.
6. Small measurements Real-time input values are displayed when the primary.
7. Telecommunication Indicates the time and date set in the internal clock.
8. Buzzer Indicates the button sound is enabled.
9. Battery capacity Indicates the capacity level of rechargeable battery.
10. Range indicator Indicates the current range and range mode for the meter.
11. Unit Indicates the measurement unit.
12. Aided function display Indicates the aided measuring function, such as LPF.
13. Aided display
Indicates the aided measuring information on input
signals.
LCD
WHAT’S INCLUDED
• One Datalogging Multimeter
• A pair of test leads
• Two K type temperature probes
• One user manual
• One temperature connector
• One charging adaptor
• One charging connector
• One USB cable
• One CD
• One zip bag
