RELATIVE VALUE
• Press the function button MENU to enter the next interface, then press the function
button REL to enter the measuring mode of relative values, then press the function
button REL to activate the measurement of relative values.
• By this time, the measurements _ basic values are primarily displayed and the
relative value and real-time measurements are secondly displayed.
• Press the function button MENU to select basic measurements to exit the
measurement of relative values.
PEAK DETECTION
• Press function button MENU to select the Peak option, then press the function
button PEAK to activate peak detection.
• Response time is 1ms. Transient values can be more accurately measured by
using peak recording function.
COMPARE MODE COMP
• Press the function button COMP to enter the measurement of compare mode.
Press the ▼ or ▲ buttons to select the settings of compare mode as follows:
Pass Mode
• Press the function button EDIT to enter the setting mode of compare types. Press
▲ or ▼ to set one of the four types as follows:
- Inner (low value ≤ input value ≤ high value)
- Outer (input value < low value or input value > high value)
- < value
- > value
• Press the function button OK to conrm the above settings. To cancel the settings,
press the function button CANCEL.
Beep Mode
• Press the function button EDIT to enter buzzer start mode. Press ▼ or ▲ to select
on of the following three items:
- PASS ON
It indicates that the buzzer starts to sound when the compare results shows as
PASS.
- FAIL ON
It indicates that the buzzer starts to sound when the compare result shows as
FAIL.
- OFF
Buzzer off. Press the function button OK to conrm the above settings. To cancel
the settings, press the function button CANCEL.
Low Value or High Value or Value
• Press the function button EDIT to compare reference values. Press the ◄ or ►
buttons to move the cursors to select locations and the ▲ or ▼ buttons to enter
different numbers.
• Press the function button OK to conrm.
• To cancel the settings, press the function button CANCEL.
• After completing the settings, press the function button START to start the
