August 2021 Service and Repair Manual
Scissor Components
Part No. 1309020GT GS
â„¢
-30m • 32m • 30 • 32 • 46 • 55 129
42 Remove the retaining fasteners from the
number 5 center pivot pin (index #4) at the
ground control side.
43 Place a rod through the number 5 center pivot
pin at the ground control side (index #4) and
twist to remove the pin.
44 Remove the retaining fasteners from the
number 5 pivot pin (index #23) at the non-
steer end.
45 Use a soft metal drift to remove the number
5 pivot pin (index #23) from the non-steer end
of the machine. Remove the number 5 outer
arm at the ground control side (index #22)
from the machine.
Crushing hazard. The number
5
o
uter arm at the ground control
side (index #22) may become
unbalanced and fall if not
properly supported when
removed from the machine.
46 Attach a lifting strap from an overhead
supporting device to the number 5 outer arm
at the battery side (index #22).
47 Remove the number 5 outer arm (index #22)
from the machine.
Crushing hazard. The number
5
outer arm at the battery side
(index #22) may become
unbalanced and fall if not
properly supported when
removed from the machine.
48 Tag and disconnect the wire harness from the
solenoid valve on the cylinder.
Component damage hazard.
Cables can be damaged if they
are kinked or pinched.
49 Attach a lifting strap from an overhead
supporting device to the lug of the rod end of
the upper lift cylinder.
50 Remove the retaining fasteners from the
upper lift cylinder rod end pivot pin (index #5).
51 Use a soft metal drift to remove the upper lift
cylinder rod end pivot pin (index #5) from the
machine.
Crushing hazard. The lift
cylinder will fal
l if not properly
supported when the pivot pin is
removed.
52 Lower the cylinder onto the linkset.
53 Attach a lifting strap from an overhead
supporting device to the number 4 outer arm
at the ground control side (index #25).
54 Remove the retaining fasteners from the
number 4 center pivot pin (index #7) at the
ground control side.
55 Place a rod through the number 4 center pivot
pin at the ground control side (index #7) and
twist to remove the pin.
56 Remove the retaining fasteners from the
number 4 pivot pin (index #26) at the non-
steer end.
57 Use a soft metal drift to remove the number
4 pivot pin (index #26) from the non-steer end
of the machine. Remove the number 4 outer
arm at the ground control side (index #25)
from the machine.
Crushing hazard. The number
4
outer
arm at the ground control
side (index #25) may become
unbalanced and fall if not
properly supported when
removed from the machine.
58 Attach a lifting strap from an overhead
supporting device to the number 4 outer arm
at the battery side (index #25).
59 Remove the retaining fasteners from the
number 4 center pivot pin (index #7) at the
battery side.
60 Place a rod through the number 4 center pivot
pin at the battery side (index #7) and twist to
remove the pin.
