Service and Repair Manual August 2021
Ground Controls
24 GS
™
-30m • 32m • 30 • 32 • 46 • 55 Part No. 1309020GT
2-1
Software Revision Level
How to Determine the Revision
Level
The machine software revision level is displayed at
the ground controls LCD display.
1 Turn the key switch to the ground controls or
platform controls position. Pull out the red
Emergency Stop button to the on position at
both ground and platform controls.
Result: The display at the platform controls
will show "CH". See example below.
Result: The display at the ground controls will
show SELECT IN/OUT and machine hours.
2 Press the scroll down button twice.
Result: The ground control LCD display will
indicate the machine model, software part number
and software revision.
3 Push in the red Emergency Stop button to the
off position at both the ground and platform
controls and turn the key switch to the off
position.
1 LCD display
2 scroll down button
