Terex GS32MT-101 Service And Repair Manual

Service and Repair Manual August 2021
Specifications
2 GS
™
-30m • 32m • 30 • 32 • 46 • 55 Part No. 1309020GT
Batteries, Maintenance-free (option)
GS-1432m, GS-1932m, GS-1932m Lite, GS-1932m XH
Voltage
12V DC
Group
24
Type
EV31A-
B
Quantity
2
Battery capacity, maximum
115AH
Reserve capacity @ 25A rate
178 m
inutes
Weight,
each 70 l
bs
32 k
g
Batteries, Maintenance-free (option)
GS-4046, GS-4655
Voltage
12V DC
Group
GC12
Type
DC150-12
Quantity
4
Battery capacity, maximum
150AH
Reserve capacity @ 25A rate
295 minutes
Weight, each
94 lbs
42,6 kg
Batteries,
Maintenance-free (option)
All other models, Models with hydraulic drive
Voltage
6V DC
Group
GC2
Type
6V-AGM
Quantity
4
Battery capacity, maximum
200AH
Reserve capacity @ 25A rate
380 minutes
Weight, each
62 lbs
28 kg
Batteries, Maintenance-free (option)
All other models, Models with electric drive
Voltage
6V DC
Group
GC2
Type
DC224-6
Quantity
4
Battery capacity, maximum
224AH
Reserve capacity @ 25A rate
441 minutes
Weight, each
68.3 lbs
31 kg
Platform Overload Pressure Transducer
(if equipped) All models except GS-3232, GS-4046,
GS-4655
Input voltage
8 t
o 30V DC
Signal voltage
1 to 5V DC
Platform Overload Pressure Transducer
(if equipped) GS-3232, GS-4046
Input voltage
8 t
o 30V DC
Signal voltage
0.25 to 6.25V DC
Angle Sensor (if equipped)
Input voltage
8 to 30V DC
Signal voltage
PWM output
Outrigger Pressure Transducer, GS-3232 only
Input voltage
8 to 30V DC
Signal voltage
1 to 5V DC
