Service and Repair Manual August 2021
Hydraulic Pump
46 GS
™
-30m • 32m • 30 • 32 • 46 • 55 Part No. 1309020GT
6 Tag, disconnect and plug the high pressure
hose from the pump. Cap the fitting on the
pump.
Bodily injury hazard. Spraying
hydraulic oil can penetrate and
burn skin. Loosen hydraulic
connections ver
y slowly to allow
the oil pressure to dissipate
gradually. Do not allow oil to
squirt or spray.
7 Remove the hydraulic power unit from the
machine.
8 Remove the pump mounting bolts. Carefully
remove the pump.
-over hazard. After replacing
ump, it is critical
to return the function speed
settings to original factory
specifications. Failure to restore
the machine to original factory
specifications could cause the
machine to tip over resulting in
death or serious injury.
