Operator's Manual First Edition • Second Printing
Work Area Safety
14 RL4 Vertical Mast Part No. 1266664
Component Damage Hazards
Do not turn the lights on unless the engine is
running. Always turn the lights off before shutting
down the engine.
Do not tow the light tower while the lamps are hot.
Hot lamps will break if moved.
Do not replace lamp bulbs with any bulbs other
than those specified on the machine and in this
manual.
Note: Lamp bulbs contain mercury (Hg). Dispose
of lamp bulbs according to local, state and federal
laws.
Be sure lamp fixture connections are properly
tightened before turning lights on.
Battery Safety
Burn Hazards
Batteries contain acid.
Always wear appropriate
personal protective
equipment, including
gloves, face shield and
long sleeve shirt when
working with batteries.
Avoid spilling or
contacting battery acid.
Neutralize battery acid
spills with baking soda
and water.
Do not use any battery charger greater than 12V to
charge the battery.
Do not remove the vent caps from the battery
when charging.
Do not expose the batteries or the charger to water
or rain during charging.
Explosion Hazards
Keep sparks, flames and lighted
tobacco away from batteries.
Batteries emit explosive gas.
Do not contact the battery terminals
or the cable clamps with tools that
may cause sparks.
Electrocution/Burn Hazards
Avoid contact with electrical terminals.
Inspect the power cord for damage prior to each
use.
Replace any damaged cord before operating.
Do not allow the power cord to become caught or
crushed while raising, lowering or rotating the
mast.
Avoid electrical shock from contact with battery
terminals. Remove all rings, watches and other
jewelry.
Lifting Hazard
Use the appropriate number of people and proper
lifting techniques when lifting batteries.
