First Edition • Second Printing Operator's Manual
Operating Instructions
Part No. 1266664 RL4 Vertical Mast 35
Engine Start - DynaGen Control Panel
(manual start)
1 Place the +12 VDC Power Toggle Switch in
the ON Position.
2 Place toggle switch in the MID/OFF position.
3 The DynaGen TG350 will start and run a
diagnostics.
4 Once complete, press the start push button on
the TG350 Module.
5 The engine will start.
6 Push the off button on the TG350 module to
stop the engine.
Engine Start - DynaGen Control Panel
(auto start)
1 Place the +12 VDC Power Toggle Switch in
the ON Position.
2 The DynaGen TG350 will start and run a
diagnostics.
3 Use the toggle switch to select either the timer
UP or the photocell DOWN to control the
starting of the engine.
4 Press the auto push button on the TG350
Module.
5 The DynaGen TG350 module will then await a
start signal from either the selected Photocell
or selected timer.
6 Using the photocell requires no special set-up.
The device is a "dusk till dawn" sensor.
7 To properly set up the timer and functions it
must be programmed prior to use. Refer to the
DynaGen TG350 manual located in the
document manuals storage for detailed
programming instructions.
Extending the Mast
1 Turn the winch handle clockwise until the mast
reaches vertical position.
2 Turn the T-handle to release the mast rotation
lock.
3 Rotate the mast to the desired postion.
4 Tighten T-handle to secure mast in the desired
position.
Retracting the Mast
1 Rotate the mast to align the arrows on the
mast before retracting.
2 Tighten T-handle to secure mast in the desired
position.
3 Turn the winch handle counter clockwise until
the mast is in the stowed position.
Rotating the Mast
1 Turn the T-handle to release the mast rotation
lock.
2 Rotate the mast to the desired position.
3 Tighten the T-handle to secure the mast in the
desired position.
