Terex RL4 User Manual

First Edition • Second Printing Operator's Manual
Specifications
Part No. 1266664 RL4 Vertical Mast 43
Specificati ons
RL4 (Vertical Mast)
Height, stowed 8 ft 6 in 2.60 m
Length, stowed 7 ft 0 in 2.14 m
Width, stowed 4 ft 9 in 1.45 m
Extended mast height 23 ft 5 in 6.68 m
Total weight, no fuel 1461 lbs 662 kg
(Machine weights vary with option configurations. See
serial label for specific machine weight.)
Tongue weight 203 lbs 92 kg
Tire size, U.S. ST175/80D13 Load C
Engine type
6 kW Kubota 16.9 hp
7 kW Kubota 16.9 hp
8 kW Kubota 16.9 hp
6 kW Kohler 10.7 hp
Fuel capacity, standard 45 gallons 170 liters
Run time, standard unit
(45 gallon tank-Kohler KDW1003-Full load) 110 hrs
Generator options Coliseum 6 kW, 60 Hz
Coliseum 7 kW, 50 Hz
Coliseum 8 kW, 60 Hz
Total lighting wattage
Four lights 4000 watts
Replacement bulbs 1000 watts
Type BT-37 Metal Halide
Tower rotation 359 degrees
non-continuous
Maximum towing speed 60 mph 97 km/h
Maximum wind speed 62 mph 100 km/h
Sound level (dba rating) 71 dba @ 23 ft / 7 m
Continuous improvement of our products is a Terex
policy. Product specifications are subject to change
without notice or obligation.

Terex RL4 Specifications

General

Light Type	Metal Halide
Number of Lamps	4
Lamp Wattage	1000 W
Fuel Type	Diesel
Generator Output	6 kW
Voltage	120/240 V
Frequency	60 Hz
Engine	Kubota D1005
Mast Height	30 ft
Weight	2200 lbs
