Operator's Manual First Edition • Second Printing
Inspections
22 RL4 Vertical Mast Part No. 1266664
Pre-operation Inspection
 Be sure that the operator’s manual is complete,
legible and in the storage container located on
the machine.
 Be sure that all decals are legible and in place.
See Inspections section.
 Check for engine oil leaks and proper fluid
level. Add oil if needed. See Maintenance
section.
 Check for engine coolant leaks and proper
coolant level. Add coolant if necessary. See
Maintenance section.
 Check for battery fluid leaks and proper fluid
level. Add distilled water if needed. See
Maintenance section.
 Check for proper tire pressure and lug nut
torque. Add air to tires if needed. See
Maintenance section.
Check the following components or areas for
damage, improperly installed or missing parts and
unauthorized modifications:
 Electrical components, wiring and
electrical cables
 Mast components
 Latches and pins
 Tires and wheels
 Trailer lights and reflectors
 Outriggers, leveling jacks and foot pads
 Winch
 Nuts, bolts and other fasteners
 Lamp fixtures, connections and bulbs
 Cable (kinks, frays and abrasions)
 Safety chains
 Engine and related components
 Fuel tanks
 Generator
 Grounding rod and lug
Check entire machine for:
 Cracks in welds or structural components
 Dents or damage to machine
 Excessive rust, corrosion or oxidation
 Be sure that all structural and other critical
components are present and all associated
fasteners and pins are in place and properly
tightened.
 Be sure the that the battery is in place and
properly connected.
 After you complete your inspection, be sure
that all compartment covers are in place and
latched.

Terex RL4 Specifications

General

Light Type	Metal Halide
Number of Lamps	4
Lamp Wattage	1000 W
Fuel Type	Diesel
Generator Output	6 kW
Voltage	120/240 V
Frequency	60 Hz
Engine	Kubota D1005
Mast Height	30 ft
Weight	2200 lbs
