Terex RL4 User Manual

Operator's Manual First Edition • Second Printing
Inspections
30 RL4 Vertical Mast Part No. 1266664
Inspection for Decals with
Symbols
Determine whether the decals on your machine
have words or symbols. Use the appropriate
inspection to verify that all decals are legible and in
place.
Part No. Decal Description Qty
52475 Label – Transport Tie-down
4
72086 Label – Lifting Point
1
133062 Label – Ground
1
133461 Instruction – Tire Specifications
2
229102 Label - Arrow
2
1266649 Cosmetic – Terex Logo, RL4
2
1266651 Label – Diesel
1
1266652 Label – Transport Diagram
1
1266654 Cosmetic – Terex Logo, RL4, Rear
door
1
1266658 Cosmetic – Terex Logo, front fairing
1
1266659 Cosmetic – Genie Logo, front fairing
1
Part No. Decal Description Qty
1266660 Cosmetic – Genie Logo, RL4, Rear
door
1
1266668 Instructions – Tongue deployment
instructions
1
1266675 Warning – Tip-over Hazard, Outriggers
1
1266676 Label – Explosion Hazard
1
1266677 Warning – Burn Hazard
1
1266678 Label – Tow Speed
1
1266679 Danger – Electrocution Hazard
1
1266886 Label – Electrocution Hazard
1
1266889 Warning – Explosion Hazard
1
1266973 Label – Read the Manual
1
1267099 Warning – Explosion/Burn Hazard
1
1267102 Danger – Inhalation Hazard
1
1267103 Label – Electrocution hazard
1
1267104 Label – Battery/Charger Safety
1
Shading indicates decal is hidden from view, i.e.
under covers

Terex RL4 Specifications

General

Light Type	Metal Halide
Number of Lamps	4
Lamp Wattage	1000 W
Fuel Type	Diesel
Generator Output	6 kW
Voltage	120/240 V
Frequency	60 Hz
Engine	Kubota D1005
Mast Height	30 ft
Weight	2200 lbs
