Terex RL4 User Manual

Operator's Manual First Edition • Second Printing
Inspections
28 RL4 Vertical Mast Part No. 1266664
Inspection for Decals with Words
Determine whether the decals on your machine
have words or symbols. Use the appropriate
inspection to verify that all decals are legible and in
place.
Below is a numerical list with quantities and
descriptions.
Part No. Decal Description Qty
52475 Label – Transport Tie-down
4
72086 Label – Lifting Point
1
97518 Instruction – Lamp Disposal
1
133062 Label – Ground
1
133461 Instruction – Tire Specifications
2
229102 Label - Arrow
2
1266647 Danger – Electrocution hazard
1
1266648 Warning – Tip-over Hazard, Outriggers
1
1266649 Cosmetic – Terex Logo, RL4
2
1266650 Danger – Explosion Hazard
1
1266651 Label – Diesel
1
1266652 Label – Transport Diagram
1
Part No. Decal Description Qty
1266653 Danger – Electrocution hazard
1
1266654 Cosmetic – Terex Logo, RL4, Rear door
1
1266655 Warning – Improper Operation
1
1266656 Instructions – Operating Instructions
1
1266657 Danger – Electrocution hazard
1
1266658 Cosmetic – Terex Logo, front fairing
1
1266659 Cosmetic – Genie Logo, front fairing
1
1266660 Cosmetic – Genie Logo, RL4, Rear door
1
1266661 Warning – Explosion Hazard
1
1266667 Instructions – Tongue deployment
instructions
1
1266881 Danger – Inhalation Hazard
1
1266883 Danger – Electrocution Hazard
1
1266884 Warning – Tow Speed
1
1266885 Warning – Explosion/Burn hazard
1
1266887 Danger – Auto-start Hazard
2
1266888 Danger – Explosion Hazard, Battery
1
Shading indicates decal is hidden from view, i.e.
under covers

Terex RL4 Specifications

General

Light Type	Metal Halide
Number of Lamps	4
Lamp Wattage	1000 W
Fuel Type	Diesel
Generator Output	6 kW
Voltage	120/240 V
Frequency	60 Hz
Engine	Kubota D1005
Mast Height	30 ft
Weight	2200 lbs
