Terex RL4 User Manual

Operator's Manual First Edition • Second Printing
Symbol and Hazard Pictorials Definitions
4 RL4 Vertical Mast Part No. 1266664
Symbol and Hazard Pic torials Definiti ons
Read the operator’s
manual
Electrocution hazard Stop engine Earth ground Electrocution hazard
Maintain required
clearance
Explosion / Burn
hazard
Disconnect battery
Read the service
manual
Keep away from
moving parts
Keep away from
moving parts
Explosion / Burn
hazard
Explosion / Burn
hazard
Corrosive acid. Explosion hazard
Do not use high
energy starting aids
on machines
equipped with glow
plugs or grid heater.
No smoking No flame No flame Burn hazard
Stay clear of hot
surfaces and
components

Terex RL4 Specifications

General

Light Type	Metal Halide
Number of Lamps	4
Lamp Wattage	1000 W
Fuel Type	Diesel
Generator Output	6 kW
Voltage	120/240 V
Frequency	60 Hz
Engine	Kubota D1005
Mast Height	30 ft
Weight	2200 lbs
