Operator's Manual First Edition • Second Printing
Controls
18 RL4 Vertical Mast Part No. 1266664
5 Duplex receptacle with GFI, 120V/20A
Convenience duplex receptacle with Ground
Fault Interrupter (GFI).
6 Hour meter
The hour meter displays the number of hours
the machine has operated.
7 Ignition switch for engine
Turn the ignition switch to the prime position
and hold the engine prime button down to
prime the engine.
Hold the prime button down and turn the
ignition switch to the start position to start the
engine.
Turn the ignition switch to the off position to
turn the engine off.
8 Engine prime button
With the ignition switch in the run position,
press and hold the prime button for
15 seconds before starting the engine.
Release the prime button when the engine
starts.
9 Alternator failure light
Light on indicates that the engine's DC
alternator isn't producing enough voltage.
10 Raise/lower switch (if equipped with electric
winch)
Move the switch up to raise and extend the
mast. Move the switch down to retract and
lower the mast.
