Operator's Manual First Edition • Second Printing
Controls
20 RL4 Vertical Mast Part No. 1266664
5 Duplex receptacle with GFI, 120V/20A
Convenience duplex receptacle with Ground
Fault Interrupter (GFI).
6 Timer
The timer is used to automatically start the
engine and turn on the lights at a preset time.
7 DynaGen controller
The DynaGen controller digitally controls and
monitors the engine functions.
8 Auto start mode control switch
Placing the switch in the UP position will select
the timer function and when placed in the
DOWN position this will select the photocell
function. The MID/OFF position is used for
manual starting of the engine. When the
photocell is turned on, the lights will go on at
dusk and go off at daylight.
9 Raise/lower switch (if equipped with electric
winch)
Move the switch up to raise and extend the
mast. Move the switch down to retract and
lower the mast.
