Terex RL4000 Operator's Manual

Operator's Manual First Edition • Second Printing
10 RL4000 • TML-4000 Part No. 116692
Work Area Safety
Tip-over Hazards
Do not raise the tower unless all
outriggers are properly deployed, the
foot pads are in firm contact with the
ground and the machine is level.
Do not set the machine up on a
surface where it cannot be leveled
using only the leveling jacks.
Do not hang any objects from the lights or the
tower.
Do not use the tower to raise material or personnel.
Do not move the machine unless the tower is
lowered to the horizontal position.
Do not raise the tower
when wind speeds may
exceed 62 mph / 100 km/
h.
Do not alter or disable
machine components that
in any way affect safety
and stability.
Do not adjust or stow the outriggers when the tower
is raised.
Be sure the tires are in good conditionand the lug
nuts are properly tightened.
Do not place ladders or
scaffolds against any part of
the machine.
Do not use the machine on a
moving or mobile surface or
vehicle.
Crushing Hazards
Do not lower the tower
unless the area below is
clear of personnel and
obstructions.
Keep hands and fingers
away from any potential
pinch points.
Collision Hazard
Check the work area for overhead obstructions or
other possible hazards.
Burn Hazards
Do not touch the lamp
fixtures while they are turned
on. Turn the lamps off and
allow them to cool before
touching.
Do not touch hot parts of the
engine or tailpipe. Use
protective gloves when
handling hot parts.
Bodily Injury Hazards
Do not use the machine indoors unless properly
ventilated.
Do not breathe exhaust fumes.
Do not work on this equipment when mentally or
physically fatigued.
Do not work on this equipment when under the
influence of drugs or alcohol.

Terex RL4000 Specifications

General

Number of Lights	4
Fuel Type	Diesel
Mast Height	9 m (30 ft)
Light Type	LED
Lamps	LED
Illuminated Area	4000 m²
