Operator's Manual
First Edition • Second Printing
Part No. 116692 RL4000 • TML-4000 33
Securing to Truck or Trailer for
Transit
Fully retract and lower the tower to the stowed
position.
Secure the tower for transport with the upper
retaining pin.
Fully retract and secure the outriggers and all
leveling jacks, except the tongue leveling jack, in
the stowed position.
Close and secure the cabinet doors
Lower the tongue outrigger jack to support the
tongue during transport.
Raise and stow the outriggers.
Transport and Lifting Instructions
Observe and Obey:
Terex Corporation provides this securement
information as a recommendation. Drivers are
solely responsible for making sure machines
are properly secured and the correct trailer is
selected pursuant to US Department of
Transportation regulations, other localized
regulations, and their company policy.
Terex customers needing to containerize any
Terex product should source a qualified freight
forwarder with expertise in preparing, loading
and securing construction and lifting equipment
for international shipment.
The transport vehicle must be parked on a level
surface.
The transport vehicle must be secured to
prevent rolling while the machine is being
loaded.
Be sure the vehicle capacity, loading surfaces
and chains or straps are sufficient to withstand
the machine weight. See the serial label for the
machine weight.
Common sense and planning must be applied to
control the movement of the machine when
lifting it with a crane or forklift.
