Terex RL4000 Operator's Manual

Operator's Manual First Edition • Second Printing
RL4000 • TML-4000 Part No. 116692
Important
Read, understand and obey these safety rules and
operating instructions before operating this
machine.
Only trained and authorized personnel shall be
permitted to operate this machine. This manual
should be considered a permanent part of your
machine and should remain with the machine at all
times. If you have any questions, call Terex.
Contents
Page
Introduction ...........................................................1
Symbol and Hazard Pictorials Definitions .............3
General Safety ......................................................5
Work Area Safety .................................................9
Legend ................................................................ 13
Controls .............................................................. 16
Pre-operation Inspection .....................................18
Function Tests .................................................... 20
Inspections .........................................................23
Operating Instructions ......................................... 28
Transport and Lifting Instructions ........................ 33
Maintenance .......................................................35
Specifications ..................................................... 37
Reporting Safety Defects .................................... 38
Contact us:
Internet: www.genielift.com
e-mail: techpubs@genieind.com
Copyright © 2009 by Terex
Terex
18340 NE 76th Street
PO Box 97030
Redmond, WA 98073-9730
First Edition: Second Printing, July 2009
Printed on recycled paper
Printed in U.S.A.

Terex RL4000 Specifications

General

Number of Lights	4
Fuel Type	Diesel
Mast Height	9 m (30 ft)
Light Type	LED
Lamps	LED
Illuminated Area	4000 m²
