Operator's Manual
First Edition • Second Printing
Part No. 116692 RL4000 • TML-4000 35
Check the Engine Coolant Level
Maintaining the engine coolant at the proper level is
essential to engine service life. Improper coolant
level will affect the engine's cooling capability and
damage engine components. Daily checks will
allow the inspector to identify changes in coolant
level that might indicate cooling system problems.
Burn hazard. Beware of hot engine parts and
coolant. Contact with hot engine parts and/or
coolant may cause severe burns.
Note: Do not remove the radiator cap.
1 Check the fluid level in the coolant recovery
tank.
2 Add fluid as needed.
Maintenance
Observe and Obey:
Only routine maintenance items specified in this
manual shall be performed by the operator.
Scheduled maintenance inspections shall be
completed by qualified service technicians,
according to the manufacturer's specifications
and the requirements specified in the
responsibilities manual.
Use only Terex approved replacement parts.
Maintenance Symbols Legend
The following symbols have been used in this
manual to help communicate the intent of the
instructions. When one or more of the symbols
appear at the beginning of a maintenance
procedure, it conveys the meaning below.
Indicates that tools will be required to
perform this procedure.
Indicates that new parts will be required to
perform this procedure.
Check the Engine Oil Level
Maintaining the proper engine oil level is essential
to good engine performance and service life.
Operating the machine with an improper oil level
can damage engine components.
1 Check the oil level with the engine off.
2 Check the oil level dipstick. Add oil if needed.
Kubota 13.6 HP Oil
Oil requirement SAE 10W-40
5.4 quarts / 5.1 liters Cold conditions
use SAE 5W-20
Perkins 13.8 HP Oil
Oil requirement SAE 10W-40
4.66 quarts / 4.41 liters Cold conditions
use SAE 5W-20
