Terex RL4000 Operator's Manual

Operator's Manual
First Edition • Second Printing
Part No. 116692 RL4000 • TML-4000 37
Specifications
Continuous improvement of our products is a Genie
policy. Product specifications are subject to change
without notice or obligation.
Model - RL4000 & TML-4000
Height, stowed 5 ft 9.5 in 1.765 m
Length, stowed 14 ft 2 in 4.331 m
Width, stowed 4 ft 6 in 1.372 m
Extended tower height 30 ft 9.114 m
Weight RL4000 1725 lbs 783 kg
TML-4000 1810 lbs 823 kg
(Machine weights vary with option configurations. See
serial label for specific machine weight.)
Maximum tongue weight 199 lbs 91 kg
Tire size, U.S. ST175/80D13 Load B
Engine type Kubota 13.6 HP
Perkins 13.8 HP
Fuel capacity 30 gallons 114 liters
Run time Kubota 38.3 hours
Perkins 37.9 hours
Generator Marathon 6 kW, 60 Hz
Total lighting wattage
Four lights 4000 watts
Replacement bulbs 1000 watts
Type BT-37 Metal Halide
Tower rotation 359 degrees,
non-continuous
Maximum towing speed 60 mph 97 km/h
Maximum wind speed rating 62 mph 100 km/h
Sound level (dba rating) 71 dba @ 23 ft / 7 m

Terex RL4000 Specifications

General

Number of Lights	4
Fuel Type	Diesel
Mast Height	9 m (30 ft)
Light Type	LED
Lamps	LED
Illuminated Area	4000 m²
