Terex RL4000 Operator's Manual

Operator's Manual First Edition • Second Printing
24 RL4000 • TML-4000 Part No. 116692
Inspections
Inspection for Decals with Words
Determine whether the decals on your machine
have words or symbols. Use the appropriate
inspection to verify that all decals are legible and in
place.
Part No. Description Quantity
28159 Label - Diesel fuel only 1
28161 Warning - Crushing hazard 2
28162 Warning - Bodily injury hazard 2
31788 Danger - Battery safety 1
38149 Label - Patents 1
52475 Label - Tie-down point 4
72009 Cosmetic - Genie logo 2
72018 Label - Raise/lower winch 1
72077 Label - Line up arrows 2
72086 Label - Lifting hook 2
72826 Label - Extend/retract winch 1
72871 Label - Convenience outlet 1
97518 Instruction - Lamp disposal 1
97602 Warning - Explosion hazard 2
97635 Warning - Bodily injury hazard 4
97666 Warning - Read manual 1
97675 Warning - Burn hazard 1
114258 Danger - No smoking 1
114431 Danger - Electrocution hazard 2
114448 Cosmetic - Terex logo 1
114464 Label - Travel lock 1
116901 Label - AC control panel 1
116902 Label - Engine control panel 1
133012 Danger - Burn/carbon monoxide hazard 1
133016 Danger - Electrocution hazard 1
Part No. Description Quantity
133017 Warning - Crushing hazard 1
133062 Label - Ground 1
133148 Danger - Electrocution hazard 2
133225 Cosmetic - Terex logo 1
133455 Danger - General safety 1
133457 Instruction - Mast stowage 2
133458 Instruction - Setup 1
133459 Warning - Towing/transport hazard 1
133460 Instruction - Operating Instructions 1
133461 Instruction - Tire specifications 2
133462 Instruction - Perkins engine specifications 1
133463 Instruction - Kubota engine specifications 1
133475 Instruction - Mast rotation 1
133476 Warning - Collision hazard 1
133477 Warning - Collision hazard 1
133478 Warning - Burn hazard 4
133482 Warning - Tip-over hazard 2
133483 Warning - Burn hazard 2
133484 Warning - Tow speed 1
133487 Cosmetic - RL4000 2
133488 Notice - Component damage 1
851691 Label - #1 1
851692 Label - #2 1
851693 Label - #3 1
851694 Label - #4 1

Terex RL4000 Specifications

General

Number of Lights	4
Fuel Type	Diesel
Mast Height	9 m (30 ft)
Light Type	LED
Lamps	LED
Illuminated Area	4000 m²
