Terex RL4000 Operator's Manual

Operator's Manual First Edition • Second Printing
4 RL4000 • TML-4000 Part No. 116692
Lifting eye.
Crushing hazard.
Stay clear of
descending tower.
Tie-down point.
Crushing hazard.
Keep away from
moving parts.
Wheel load.
Carbon Monoxide
hazard.
Wear protective
clothing.
Burn hazard
Stay clear of hot
exhaust.
Symbol and Hazard Pictorials Definitions
Stay clear of hot
surfaces.
Burn hazard
Keep away from
moving parts.
Deploy outriggers
before raising
mast.
Burn hazard
Stay clear of hot
surfaces.
Burn hazard
Shattering glass
hazard
Tip-over hazard
Tip-over hazard

Terex RL4000 Specifications

General

Number of Lights	4
Fuel Type	Diesel
Mast Height	9 m (30 ft)
Light Type	LED
Lamps	LED
Illuminated Area	4000 m²
