Width of bucket mm 1,850 1,850
Capacity in accordance with ISO 7546 (max. density = 1.8 t/m ³) approx. m³ 0.8 0.8
Payload in bucket kg 1,440 1,440
Dump height at 45° dump angle approx. mm 2,550 2,550
Dump reach at max. dump height approx. mm 700 710
Max. bucket hinge pin height approx. mm 3,200 3,220
Reset angle ° 50 50
Dump angle at max. dump height ° 45 45
Digging depth, horizontal bucket approx. mm 100 110
Lift capacity at ground level (ISO 14397-2) approx. N 48,000 48,400
Ripping force at cutting edge of bucket approx. N 45,900 47,300
Tipping load, straight (ISO 14397-1) approx. kg 3,720 3,720
Tipping load, articulated (ISO 14397-1) approx. kg 3,280 3,280
Work cycle times, "Lift" sec. 4.7 4.9
"Lower" sec. 3.2 3.4
Dumping in uppermost position "In" sec. 1.1 1.1
"Out" sec. 1.1 0.8
Stability conforms to DIN 24094
3.14 Bucket
Width
mm
Capacity, heaped
m³
Max. density (γ)
t/m
3
General-purpose bucket 1850 0.8 1.8
Multi-purpose bucket 1850 0.75 1.6
Earth bucket 1850 0.9 1.6
Light-material bucket 1850 1.0 1.2
Super light-material bucket 1950 1.2 0.8
Side-dump bucket 1850 0.7 1.8
High-tip bucket 1850 0.7 1.2
