Terex TL80 - Breather

7 Maintenance and Care
90 TL80
7.9.12 Breather
Replace the breather if it is dirty, e.g. due
to oil fumes.
• Unscrew the oil dipstick (54/1).
• Remove the breather (54/2) and dispose of
according to regulations.
• Clean the screen (54/4) and check for damage;
replace if required.
• Screw in new breather (54/2) with O-ring (54/3)
and tighten by hand.
• Screw back in the oil dipstick.
L834-054
1
2
4
3
Fig. 54 Breather
