4 Operation
50 TL80
4.8.4 Driving on roads
Before driving on open roads, the following points
have to be observed:
The wheel loader must be equipped as
stipulated by the regulations authorizing
the use of vehicles for road traffic in the
user's country.
• Empty the bucket and tilt back completely.
• Attach the protective device on the front bucket
edge.
• Secure the side-dump bucket with socket pins.
• Completely retract the high-tip bucket.
• Fold up the forks of the fork lift attachment, lock
in place and secure against lateral shifting.
Rigid forks must be dismounted
before driving on public roads!
• Raise the lift frame as far as the height color
mark (18/1) until sufficient ground clearance is
secured.
• Set the travel direction preselection rocker
switch on the joystick (20/7) and on the
instrument panel 20/36) to "0" (neutral position).
• Switch off the working hydraulics (20/35).
Only shift when machine is at
standstill!
• Check the function of the direction indicators,
hazard warning lights, horn, low/high beam.
• Close the cab door.
Fig. 18 Height color mark
Fig. 20 Operation
