Operation 4
TL80 39
Description of fig. 10.1 - Operator controls
1 Direction indicator, horn, low/-high beam (steering-column switch)
2 Brake-inching pedal
3 Accelerator pedal
4 Steering wheel - tilt and height adjustment
5 Operation - Additional control circuit
6 Control lever - loader installation
7 Travel direction preselection (without function if working hydraulics are disabled)
8 Impulse mode - float position
9 Parking brake
10 Power socket
11 Fuse carrier
12 Fresh air - recirculating air
13 Radio
14 Control rod for mechanical quick-attach device
15 Washer fluid tank
