Working Operation of the machine 5
TL80 55
Operation - Float position
The float position must always be
switched off unless operated. Switch
(23/48) in Position "0".
Impulse Mode
• Lower the bucket onto the ground
• By pressing the preselection button for float
position (23/48) once to the left or on the
symbol, the "impulse float" function is activated
and can be engaged via the float latch (23/8) on
the coordinate lever.
• By pressing the "float position" preselection
button (23/48) to the right or deactivating the
starter preheat switch (23/50), the float position
is deactivated.
Continuous operation
• Lower the bucket onto the ground.
• By pressing the preselection button for float
position (23/48) twice to the left or on the
symbol, "continuous float" is activated.
• By pressing the "float position" preselection
button (23/48) once to the right or deactivating
the starter preheat switch (23/50), the float
position is deactivated.
Fig. 23 Operation
