Grease all lubricating points with multi-purpose grease
The intervals stated are valid for one-shift operation
Item
Lubricating point
Number daily weekly Chapter
1 Tilt cylinder - Tilt control lever 1 X --
2 Lift frame - Tilt control lever 1 X --
3 Lift cylinder - Lift frame 1 (2)* X --
4 Tilt cylinder - Front-end 1 X --
5 Lift frame - Front-end 2 X --
6 Lift cylinder - Front-end 1 (2)* X --
7 Lift frame - Quick-attach system 2 X --
8 Linkage - Quick-attach system 1 X --
9 Tilt control lever - Linkage 1 X --
10
Mechanical quick-attach system
Hydraulic quick-attach system
3
2
X
X
--
11 Steering cylinder - Front-end 1 X --
12 Articulation 3 X --
13 Steering cylinder - Rear-end 1 X --
14 Rear axle bearing 1 X --
15 Door hinges 4 X --
16 Multi-purpose bucket 2 X --
17 Multi-purpose bucket cylinder 4 X --
* ( ) Z kinematics
In the case of special operating conditions, e.g. working on sandy ground, the lubrication intervals
should be shortened, in order to encourage self-cleaning of bearing points.
