Table 2.2 IBUC 2e Transmit Frequency Plans
Signal Standard C-band Palapa C-band Insat C-band Extended C-band Full C-band
L-band
(Inverting)
950 MHz to 1525 MHz 975 MHz to 1275 MHz 1150 MHz to 1450 MHz 950 MHz to 1750 MHz 975 MHz to 1850 MHz
LO frequency
(Inverting)
7.375 GHz 7.700 GHz 8.175 GHz 7.600 GHz 7.700 GHz
L-band
(Non-Inverting)
950 MHz to 1525 MHz 1125 MHz to 1425 MHz 965 MHz to 1265 MHz 950 MHz to 1750 MHz 950 MHz to 1825 MHz
LO frequency
(Non-Inverting)
4900 MHz 5300 MHz 5760 MHz 4900 MHz 4900 MHz
RF frequency
5.850 GHz to 6.425 GHz 6.425 GHz to 6.725 GHz 6.725 GHz to 7.025 GHz 5.850 GHz to 6.650 GHz 5.850 GHz to 6.725 GHz
Output Power
5, 10, 20 watts 5, 10, 15, 20 watts 5, 10, 15, 20 watts 5, 10, 15, 20 watts 5, 10, 15, 20 watts
Signal Standard Ku-band (Band1) Full Ku-band (Band 2) Low Ku-band (Band 3)
L-band
950 MHz to 1450 MHz 950 MHz to 1700 MHz 950 MHz to 1450 MHz
LO frequency
(Inverting)
— — —
LO frequency
(Non-Inverting)
13.050 GHz 12.800 GHz 11.800 GHz
RF frequency
14.000 GHz to 14.500 GHz 13.750 GHz to 14.500 GHz 12.750 GHz to 13.250 GHz
Output Power
4, 8, 12, 16 watts 4, 8, 12, 16 watts 4, 8, 12, 16 watts
