Thresholds for alarms that are user configurable can be set by using any of the M&C
interfaces described in this chapter.
To disable the multifunction LED use the ASCII command CLE on page C-13.
Ethernet
Using Ethernet, you can communicate with the IBUC 2, IBUC 2e, IBUC 2G,
IBUC R or IBUC G through SSHv2, SNMPv3 or through the onboard Web Server
(HTTPS). The IBUC uses a static IP addressing structure and does not support DHCP
(Dynamic Host Control Protocol).
The IBUC is configured at the factory, as follows:
IP Address 192.168.1.21
IP Gateway 192.168.1.1
Subnet Mask 255.255.255.0
Table 5.1
Default Alarm Configuration
Alarm State
Major Minor None
Tx Alarms
User
Configurable
Solid RED
Flashing Red
Log Only
DRO out of lock No X
Tx Output Level High Yes X
Tx Output Level Low Yes X
Tx Input Level High Yes X
Tx Input Level Low Yes X
High Temperature Alarm Yes X
Tx Simulated Fault No X
10 MHz Reference Fault No X
Input Voltage Out of Range No X
Switch Fault No X
Input Current Out of Range No X
AGC/ALC Target Out of Range No X
AGC/ALC Out of Range No X
Overdrive Alarm No X
Tx Muted Alarm No X
