System Cabling Requirements
Cables and Connectors
Interface connectors for the Cyber Hardened IBUC 2, IBUC 2e, IBUC 2G, IBUC R
or IBUC G and their mates are listed in Table 3.3. Additional mating connectors and/
or cables can be ordered from Terrasat at optional items.
1. Three-pin J3 connector is only used in AC powered units.
2. Connector used for High Power units
3. Ethernet port does not support PoE
Table 3.3 Interface Connector Schedule
Reference
Designator
Function Interface Connector Interface Connector Mate
J1 Tx Input
TYPE-N SOCKET
(TYPE-F SOCKET optional)
TYPE-N PLUG
(TYPE-F PLUG optional)
J2
M&C
Interface
AMPHENOL CIRCULAR, BOX
MOUNTING SOCKET, 19S
(PT02E-14-19S (027))
AMPHENOL CIRCULAR,
STRAIGHT PLUG, 19P
(PT06E-14-19P (475))
J3 DC Power
AMPHENOL CIRCULAR, BOX
MOUNTING SOCKET
(ACS02E14S-6P (553))
AMPHENOL CIRCULAR
STRAIGHT PLUG
(ACS06E14S-6S(553))
J3
1
AC Power
CONNECTOR, MALE
RECEPTACLE, 3P
(AMPHENOL
C016 20C003 100 12)
CONNECTOR, FEMALE
PLUG, 3P
(AMPHENOL
C016 20D003 110 12)
J3
2
AC Power
CONNECTOR, MALE
RECEPTACLE, 4P
(HIROSE
H/MS3102A22-22P-D-T(73))
CONNECTOR, FEMALE
PLUG, 4P
(HIROSE
H/MS3106A22-22S-D-T(73))
J4
3
Ethernet
RJ45-IP67 SHIELDED INLINE
CONNECTOR WITH CAP
RJ45-IP67 PLUG
RF Output C-band
CPR137, CPRG WAVEGUIDE OR
TYPE-N SOCKET
CPR137, CPRF WAVEGUIDE
OR TYPE-N PLUG
RF Output X-band CPR112, CPRG WAVEGUIDE CPR112, CPRF WAVEGUIDE
RF Output Ku-band
WR75 COVER FLANGE WITH
GROOVE
WR75 COVER FLANGE
RF Output Ka-band
WR28 COVER FLANGE WITH
GROOVE
WR28 COVER FLANGE
