Terrasat IBUC 2 - J4 - Industrial Ethernet Connector

General Requirements | 3-17
Engineered to Endure
J3 – AC Power AC Power for high power units is supplied via specialized 4 pin
Milspec connector. The connector is configure as described in
J4 – Industrial Ethernet Connector The industrial Ethernet connector is an
IP67-rated RJ45 Cat. 5e interface with a locking protective cover. The connector is
configured as described in Table 3.8.
RF Output The types of waveguide used for various bands of the IBUC are listed in
Table 3.3 on page 3-13.
Table 3.7 Pin Assignments for Milspec High-Power AC Connector J3
Pin Function
A Ground
B Neutral
C Line
D Ground
Table 3.8 Pin Assignments for Ethernet Connector J4
Pin Function
1 TCP/IP Tx(+)
2 TCP/IP Tx(–)
3 TCP/IP Rx(+)
4 Not Used
5 Not Used
6 TCP/IP Rx(–)
7 Not Used
8 Not Used
!
WARNING
The IBUC Ethernet circuit does not support Power Over Ethernet (PoE)
functionality. Routing PoE connection to port J4 might irreversibly
damage IBUC unit.
