Terrasat IBUC 2 - Table 2.5 IBUC G Transmit Frequency Plans

System Components | 2-7
Engineered to Endure
Table 2.5 IBUC G Transmit Frequency Plans
Signal Standard C-band Palapa C-band Insat C-band Extended C-band Full C-band
L-band
(Inverting)
950 MHz to 1525 MHz 975 MHz to 1275 MHz 1150 MHz to 1450 MHz 950 MHz to 1750 MHz 975 MHz to 1850 MHz
LO frequency
(Inverting)
7.375 GHz 7.700 GHz 8.175 GHz 7.600 GHz 7.700 GHz
L-band
(Non-Inverting)
950 MHz to 1525 MHz 1125 MHz to 1425 MHz 965 MHz to 1265 MHz 950 MHz to 1750 MHz 950 MHz to 1825 MHz
LO frequency
(Non-Inverting)
4900 MHz 5300 MHz 5760 MHz 4900 MHz 4900 MHz
Output Power
400 watts 400 watts 400 watts 400 watts 400 watts
Signal X-band Standard Ku-band (Band1) Full Ku-band (Band 2) Low Ku-band (Band 3) Ka-band
L-band
950 MHz to 1450 MHz 950 MHz to 1450 MHz 950 MHz to 1700 MHz 950 MHz to 1450 MHz 1000 MHz to 2000 MHz
LO frequency
(Inverting)
— — — — —
LO frequency
(Non-Inverting)
6.950 GHz 13.050 GHz 12.800 GHz 11.800 GHz 28.000 GHz
RF frequency
7.900 GHz to 8.400 GHz 14.000 GHz to 14.500 GHz 13.750 GHz to 14.500 GHz 12.750 GHz to 13.250 GHz 29.000 GHz to 30.000 GHz
Output Power
400 watts 150, 200, 300, 400 watts 150, 200, 300, 400 watts 200, 300, 400 watts 5, 10, 16, 20, 25, 40 watts
‘
Signal Ka-band Ka-band
L-band
1000 MHz to 1500 MHz 1000 MHz to 2000 MHz
LO frequency
(Inverting)
— —
LO frequency
(Non-Inverting)
28.500 GHz 29.000 GHz
RF frequency
29.500 GHz to 30.000 GHz 30.000 GHz to 31.000 GHz
Output Power
80 watts 80 watts
