1.6.3 Optional Features
 A-Base Test Board Adapter
 1180 K-Base Test Board Adapter
 Adapter for calibrating the unit
 Diamond Support with Calibration Service
 Stand-alone calibration of the unit
 Wedge (2490) and Mechanical Pickup (2480) for testing mechanical meters
General Specifications
1.7
1.7.1 Input Characteristics
PARAMETERS
DATA
Power Supply
120 VAC, 10A
Supply Frequency
45-65Hz
1.7.2 Dimensions
PARAMETERS
DATA
Height
18.19” (46.20 cm)
Width
15.50” (39.37 cm)
Depth
13.13” (33.35 cm)
Weight
52 lbs (23.58 kg)
1.7.3 Measurements Accuracy
Valid for 50Hz/60Hz and Current of 0.2A to 50A.
PARAMETERS
DATA
Voltage Measurement Accuracy
±0.02%
Current Measurement Accuracy
±0.02%
Power Measurements Accuracy
(Watts / VA / VAR)
±0.04%, ±0.02% typical
Energy Measurements Accuracy
(WHrs / VAHrs / VARHrs)
±0.04%, ±0.02% typical
