Tesmec DLR300 - ACCESS TO THE MAIN MENU; SETTING THE WORK PARAMETERS


Page 6



ATTENTION: press the button to activate or deactivate the screen light.
ATTENTION: if the machine is used at low temperatures, the sensor and the pull
recorder must be connected and electrically switched on for approx. 15 min before
implementing any operation.
The various functions can then be accessed via the keyboard.
3.3 ACCESS TO THE MAIN MENU
To access the management menu of the instrument, when the current date and time appear on
the display:
& Press: for a few seconds
 The following appears: RECORDINGS MANAGEMENT
WORK PARAMETERS
MACHINE PARAMETERS
SETTING THE CLOCK
DISPLAY CONTRAST
CONFIGURATION MANAGEMENT
The instrument displays a menu to manage recordings and parameters. To access the desired
option:
& Press: to select the next function
or
& Press: to select the previous function
or
& Press: to access the selected function
or
& Press: to exit the main menu and return to the initial display (current
date and time).
3.4 SETTING THE WORK PARAMETERS
The parameters pertaining to a correct reading must be entered before each recording. This
programming level requires the user to access the main menu, then:
& Press: or to navigate the menu and select the WORK
PARAMETERS function
♦ Select: WORK PARAMETERS
& Press: to access the configuration page of the work parameters;
 The following appears: CABLE DIAMETER (mm):
SAMPLING (m):
PULL LIMIT VALUE (daN):
PRINT IN REAL TIME:
MEASUREMENTS:
LANGUAGE:
3.4.1 SETTING THE ROPE DIAMETER
♦ Select: CABLE DIAMETER (mm): 10.0 (or another pre-set value) is the
diameter of the rope or conductor expressed in mm with one
decimal place.
& Press: or until the desired value is selected.
