Tesmec DLR300 - Setting the Limit Value; Setting the Units of Measurement


Page 7



ATTENTION: the values range from 1.0 to the pre-set value in the
MAX ROPE DIAM. (mm) item (refer to Chap 4.1.2.2).
& Press: to confirm the selection and move on to the next work parameter
or
& Press: to return to the main menu without saving any changes made.
3.4.2 SETTING THE SAMPLING
♦ Select: SAMPLING (m): 10 (or another pre-set value) is the recording step in
metres, i.e. the data will be read every given number of metres of
cable and will be saved and printed
& Press: or until the desired value is selected.
ATTENTION: the values range from 1 to 100 m
& Press: to confirm the selection and move on to the next work parameter
or
& Press: to return to the main menu without saving any changes made.
3.4.3 SETTING THE LIMIT VALUE
♦ Select: PULL LIMIT VALUE (daN): 4000 (or another pre-set value) is the
threshold value of the applied pull, in daN, above which the
instrument alarm status is triggered.
& Press: or until the desired value is selected.
ATTENTION: the values range from 1 to the pre-set value in the
FULL SCALE (daN) item (refer to Chap 4.1.3.2).
& Press: to confirm the selection and move on to the next work parameter
or
& Press: to return to the main menu without saving any changes made.
3.4.4 SETTING THE TYPE OF PRINT
♦ Select: PRINT IN REAL TIME: No (or Yes). If NO is selected, the recorded
data will be saved to possibly be printed at a later stage, whereas if
YES is selected, the instrument will print the report in real time while
the machine is running.
& Press: or to select the desired value.
& Press: to confirm the selection and move on to the next work parameter
or
& Press: to return to the main menu without saving any changes made.
3.4.5 SETTING THE UNITS OF MEASUREMENT
♦ Select: MEASUREMENTS: Metric (or Imperial)
& Press: or until the desired units are selected.
& Press: to confirm the selection and move on to the next work parameter
or
& Press: to return to the main menu without saving any changes made.
