Page 29
stick
Allows the user to transfer the instrument configuration and
calibration data on to a USB stick, thereby making it available for
recovery operations to be implemented on the instrument in the
future
The following appears: INSERT THE PEN DRIVE
Insert the USB stick into the relative slot found on the upper panel of the instrument and
& Press: to start the saving operation
or
& Press: to return to the configuration management page.
The following appears: OPERATION IN PROGRESS
PLEASE WAIT
Once the writing phase is complete, the device will communicate whether this has been
completed successfully:
The following appears: SAVING COMPLETE
THE PEN DRIVE CAN BE REMOVED
After removing the USB stick:
& Press: to return to the configuration management page.
ATTENTION: do not change the name and extension of the configuration file as it
then becomes unusable.
4.2.3 PRINT CONFIGURATION
& Press: or to navigate the configuration management menu and
select the PRINT CONFIGURATION function
Allows the current configuration parameters to be printed.
♦ Select: PRINT CONFIGURATION
& Press: to print the configuration data
To stop printing:
& Press: to exit printing and return to the configuration management
menu.
