3.9.1 DISPLAY CABLE LAYING OPERATIONS
& Press: or to navigate the cable laying management menu and
select the DISPLAY RECORDING function
♦ Select: VIEW RECORDING
& Press: to access the display page of the recorded cable laying operations
 The following appears: VIEW RECORDING
N:xx dd.mm.yy. hh:mm
END: dd.mm.yy. hh:mm
& Press: or until the desired cable laying operation is selected.
& Press: to confirm the selection
or
& Press: to exit the display page and return to the cable laying
management page.
The instrument displays the recorded data in sequence. To move the display forward or
backward:
& Press: or
Once viewing is complete:
& Press: to exit the display page and return to the cable laying
management page.
3.9.2 PRINT CABLE LAYING OPERATIONS
& Press: or to navigate the cable laying management menu and
select the PRINT RECORDING function
♦ Select: PRINT RECORDING
& Press: to access the print page of the cable laying operations
 The following appears: PRINT RECORDING
N:xx dd.mm.yy. hh:mm
END: dd.mm.yy. hh:mm
& Press: or until the cable laying operation to be printed is selected.
& Press: to confirm the selection
or
& Press: to exit the display page and return to the cable laying
management page.
To stop printing:
& Press: to exit printing and return to the cable laying management page.
To see how the data will be printed, refer to paragraph 3.7.
Once the data is printed, the instrument asks the user whether the graph should also be printed:
 The following appears: PRINT THE GRAPH? NO
& Press: or until YES is selected to print the graph
or
& Press: or until NO is selected for the graph not to be printed.
& Press: to confirm the selection made
