Tesmec DLR300 - SETTING THE CALIBRATIONS


Page 24



menu
or
& Press: to return to the menu without saving any changes made
4.1.4.4 SETTING THE POSITIVE DIRECTION
♦ Select: POSIT. DIRECTION: Puller (or Tensioner). Enter the mode to be
set for positive stringing operations.
ATTENTION: this parameter is only
available if BIDIRECTIONAL
mode was selected in the previous step
& Press: to select Tensioner
or
& Press: to select Puller
& Press: to confirm the selection and return to the machine parameter
edit menu
or
& Press: to return to the menu without saving any changes made
4.1.5 SETTING THE CALIBRATIONS
& Press: or to navigate the menu and select the CALIBRATIONS
function
♦ Select: CALIBRATIONS
& Press: to access the settings page of the calibration parameters
 The following appears: SENSOR RESET:
PULLER CALIBRATION:
TENSIONER CALIBRATION:
PRINT CALIBRATION:
4.1.5.1 SENSOR RESET
& Press: or to navigate the menu and select the SENSOR RESET
function
♦ Select: SENSOR RESET
& Press: to access the sensor reset page
 The following appears: ZERO ACQUISITION
Current zero bit: xx
Read Bit: xx.
This procedure lets the sensor signal value be acquired with null
stress applied (zero-bit). Discharge the load cell or the pressure
transducer completely: the corresponding bit appear on the display;
the value relative to a load cell sensor must be close to 0 (zero),
whereas the value relative to a pressure transducer sensor must be
close to 16000. The zero value is distinct from the operating mode.
& Press: to confirm the selection and return to the calibration menu
or
& Press: to return to the menu without saving any changes made
