TESTO 454 User Manual

8Main menu
8.3 Memory
8.3.3 Programs 1-3
Measurements can be controlled via 3 freely definable measuring/saving programs. The
channel, starting criteria, measuring rate, measurement duration or number of values are
defined in the programs 1-3. The programs are started once the “starting criterion” is ful-
filled. The starting criterion is checked at the measuring rate: if a slow rate has been set it
is advisable to set a an intermediate rate when checking the starting criterion (see Chapter
8.6.5). All 3 programs can be started independently of each other, they save all of the con-
nected probe values at the set measuring rate. “Programming 1” can be taken as an exam-
ple for all 3 programmings.
17
Example 1: Measurement with activated “Program 1”, Starting criterion: “Overrun”
Example 2: Measurement with two activated programs (Prog. 1 and Prog. 2),
Starting criteria: “Exceeding”
Display, channel 1
Display, channel 1
Time
Time
Limit value of
starting criterion
”Exceeding”
Limit of starting
criterion
“Exceeding”
Prog. 2
Limit of
starting criterion
“Exceeding”
Prog. 1
Prog.1
active
Prog. 2
active
Start of program 1 when
the programmed starting
criterion is entered
xxxxx =
Checking the
starting criterion
at a quicker rate
(“Device” menu,
“Intermediate
rate” submenu)
End of program 1, the starting
criterion is lifted
The program can be ended pre-
maturely via “Measuring rate” or
“Number of values
Progression of parameter at channel 1
Progression of parameter at channel 1
x x x x x x x x x x x x x x x x x x x x x x x x x x x x x x x x x x x x x x x x
Prog.1
active
Changing measuring rate e.g. high
resolution in critical areas
Data acquisition corresponding to the
“Measuring rate”
