TESTO 770 - 9.2.2 testo 770-3 (0590 7703)

9 Technical data
28
Feature
Measuring
range
1
Resolution
Accuracy
5.120 µF
0.001 µF
± (1.5% of m.v. + 5 digits)
51.20 µF
0.01 µF
± 10 % typically
100.0 µF
(15 s)
7
0.1 µF
± 10 % typically
Temperature with
adapter
(testo 770-2)
8
-20 to 500 °C
0.2 °C
-20 to 0 °C: +/- 2 °C
0 °C to 100 °C: +/- 1 °C
100 °C to 250 °C:
+/-1.5 %
>250 °C: +/-2 %
Figures correspond to +23 °C ± 5 °C at <80% rel. humidity. Temperature coecient:
0.15 x specied accuracy per 1 °C (<18 °C and >28 °C)
9.2.2 testo 770-3 (0590 7703)
Feature
Measuring
range
9
Resolution
Accuracy
DC voltage
6.000 V
60.00 V
600.0 V
1 mV
10 mV
100 mV
± (0.8 % of m.v. + 3 digits)
AC voltage
10
,
11
,
12
6.000 V
60.00 V
600.0 V
1 mV
10 mV
100 mV
± (1.0 % of m.v. + 3 digits)
DC current
- jaws [A]
- jack [μA]
600 A
600 μA
0.1 A
0.1 μA
± (2.0 % of m.v. + 5 digits)
± (1.5 % of m.v. + 5 digits)
AC current
11
- jaws [A]
13
- jack [μA]
10,12
600 A
600 μA
0.1 A
0.1 μA
± (2.0 % of m.v. + 5 digits)
± (1.5 % of m.v. + 5 digits)
7
Maximum measurement duraon is 15 s
8
Does not include the measurement error of the temperature probe. The specied accuracy is
the sum total of the measurement errors of the thermocouple adapter and the testo 770.
9
The lower measuring ranges are only specied from 5% (does not apply to DC current / AC
current measurements with the current probe)
10
Signal bandwidth 40 Hz to 1 kHz
11
In the case of a mixed signal (AC + DC), only the purely AC component is taken into account
12
As the frequency increases (over 400 Hz), the accuracy deteriorates
+/- (2.5% of m.v. + 3 digits) for 400Hz to 750Hz / +/- (5.0% of m.v. + 3digits) for 750Hz to 1000Hz
13
Frequency of AC currents up to 400 Hz
