TESTO 872 - Superresolution

7 Performing the measurement
32
Set time/date
Time and date can be set. The time and date format are set automatically based
on the selected user interface language.
1
- Select Configuration → Settings → Set time/date.
2
- Move the joystick to the right/left to select the required setting option.
3
- Move the joystick up/down to set the value.
4
- After setting all values, select ✔ and press OK.
Temperature unit
The temperature unit can be set.
1
- Select Configuration → Settings → Temperature unit.
2
- Move the joystick up/down to select the required unit and then
press OK.
Power-save options
The illumination intensity of the display can be set. A lower intensity increases
the battery life.
The time until automatic switch-off can be set.
1
- Select Configuration → Settings → Power-save options.
2
- Move the joystick up/down to select the required intensity level
and then press OK.
7.9.2 SuperResolution
SuperResolution is a technology to improve image quality. For each shot a
sequence of images is saved in the thermal imager. Using the camera, App, or
PC software, an image is recorded with four times more measurement values
(no interpolation). The geometric resolution (IFOV) is improved by a factor of
1.6.
To use the function, the following conditions must be fulfilled:
• The camera is hand-held.
• The objects to be imaged do not move.
1
- Select Menu → Configuration → SuperResolution.
2
- Press OK to enable or disable the function.
