TESTO 872 - Save JPEG; Connectivity

7 Performing the measurement
33
7.9.3 Save JPEG
Infrared images are saved in BMT (image with all temperature data) format. The
image can also be saved in JPEG format (without temperature data) at the
same time. The image content corresponds to the infrared image shown on the
display, including scale display and image marks for the selected measuring
functions. The JPEG file is saved under the same file name as the associated
BMT file and can be opened on the PC, even without using the IRSoft PC
software.
1
- Select Menu → Configuration → Save JPEG.
2
- Press OK.
3
- Move the joystick up/down until On/Off is selected.
4
- Add a date/time stamp to a JPEG file if required. Turn function on or
off for this.
5
- Select ✔ and press OK.
7.9.4 Connectivity
Enable/disable WLAN or Bluetooth
®
1
- Select Menu → Configuration → Connectivity.
2
- Move the joystick to the right (>).
- Select WLAN and press OK to enable
(✔) or disable the function.
- Select Bluetooth and press OK to enable
(✔) or disable the function.
3
- Press Esc to cancel the process.
If there is an active Bluetooth connection and a WLAN connection is
activated in addition, the Bluetooth data transfer is continued. However,
it is not possible to establish a new connection to a humidity probe.
