Schematics, BOM, Layout, and ECG Cable Details
A.3 Bill of Materials
Table 13 lists the bill of materials for the ADS1x98ECG-FE.
Table 13. Bill of Materials: ADS1x98ECG-FE
Count RefDes Description Size Part Number MFR
1 NA Printed wiring board 6514709 TI
15 C1, C2, C3, C4, C5,
C6, C11, C17, C47,
C48, C49, C52, C58,
C76, C77
Capacitor, ceramic 1µF 25V 10% X5R 0603 GRM188R61E105KA12D Murata
0 C7, C8, C15, C19,
C21, C22, C25, C27,
C34, C36, C38, C40,
C41, C42, C43, C44,
C56, C62, C67, C78,
C79, C81, C83, C85,
C87, C89
Not installed
1 C9 Capacitor, ceramic 22µF 6.3V 10% X5R 0805 JMK212BJ226KG-T Taiyo Yuden
11 C10, C45, C46, C50,
C51, C54, C55, C60,
C61, C65, C66
Capacitor, ceramic 10µF 10V 10% X5R 0805 GRM219R61A106KE44D Murata
10 C12, C13, C14, C16,
C18, C57, C69, C70,
C94, C95
Capacitor, ceramic 0.1µF 50V 10% X7R 0603 GRM188R71H104KA93D Murata
1 C20 Capacitor, ceramic 10nF 50V 10% X7R 0603 GRM188R71H103KA01D Murata
20 C23, C24, C26, C28,
C29, C30, C31, C32,
C72, C73, C74, C75,
C80, C82, C84, C86,
C88, C91, C92, C93
Capacitor, ceramic 47pF 50V 5% C0G 0603 GRM1885C1H470JA01D Murata
0 C33, C35, C37 Not installed
0 C39 Not installed
4 C53, C59, C63, C64 Capacitor, ceramic 2.2µF 6.3V 10% X5R 0603 GRM185R60J225KE26D Murata
2 C68, C71 Capacitor, ceramic 100µF 10V 20% X5R 1210 LMK325BJ107MM-T Taiyo Yuden
1 C90 Capacitor, ceramic 1000pF 50V 5% X7R 0603 C1608X7R1H102J TDK
0 D1 - D10 Not installed
1 J1 Connector, DSUB Rcpt 15-position R/A PCB SLD D15S13A4GV00LF FCI
2 J2, J3 10x2x0.1 female (installed from bottom side) SSW-110-21-FM-D Samtec
1 J4 5x2x0.1 female (installed from bottom side) SSW-105-21-FM-D Samtec
0 J5 Not installed
4 JP1, JP4, JP5, JP16 2-position jumper 0 .1" spacing TSW-102-07-T-S Samtec
0 JP3 Not installed
0 JP6, JP7, JP8, JP9,
JP10, JP11, JP12,
JP13, JP14, JP17,
JP25
Not installed
9 JP2, JP15, JP18,
JP19, JP20, JP21,
JP22, JP23, JP24
3-position jumper 0.1" spacing TSW-103-07-T-S Samtec
8 JP26, JP27, JP28,
JP29, JP30, JP31,
JP32, JP33
2x2x0.1, 2-pin dual row header TSW-102-07-T-D Samtec
5 L1 - L5 Ferrite bead 470Ω 0805 BK2125HM471-T Taiyo Yuden
0 R1, R4, R5, R11,
R12, R15, R16, R19,
R20, R23, R24, R27,
R28, R31, R32, R35,
R36, R41, R42, R45 -
R51, R54, R55, R58 -
R66, R68, R69, R70
Not installed
0 R2 Not installed
5 R3, R71, R72, R73,
R74
Resistor, 0.0Ω 1/10W 5% SMD 0603 RC0603JR-070RL Yageo
