EPWM1A
EPWM2A
EPWM1B
EPWM2B
TZ1
TZ2
TZ3
ECAP1
‘2808
I
1
I
2
I
in
I
setSD
I
setCL1
I
setCL2
CL1
CL2
ShutDown
Fault Management Support
Trip Zones:
6 independent zones (TZ1~TZ6)
Force High, Low or HiZ on trip
One-time trip
catastrophic failure
Cycle-by-cycle
current limit mode
TZ1~TZ6 can trigger interrupt
