3.2 EVM High-Level Summary
The DP83869EVM supports SMI through J15 using pin 26 for MDIO and 28 for MDC. These pins can be
connected to an MSP430 Launchpad, which can be used for USB-2-MDIO control.
Table 3-1. EVM Applications
NO. DP83869 MODE APPLICATIONS HOW TO USE
1 RGMII to Copper Run traffic between RGMII and Copper. Connect to DP83867 RGMII EVM or MAC System
using Header pins/Samtech connector.
Perform IEEE and UNH compliance testing Use onboard MSP430 to activate test mode
waveform on DP83869.
Run EMI/EMC Test on EVM Use internal PRBS and loopback.
Measure Power Dissipation Connect external power supplies.
External MAC loopback Connect external MAC to headers/Samtech
connector.
2 SGMII to Copper Run traffic between SGMII and Copper. Connect to DP83867 SGMII EVM or MAC System
using SMA connector.
Perform IEEE and UNH compliance testing Use onboard MSP430 to activate test mode
waveform on DP83869.
Run EMI/EMC Test on EVM Use internal PRBS and loopback.
External SGMII loopback Use SMA cable for Passive Loopback.
3 RGMII to Fiber Ethernet Run traffic between RGMII and Fiber Ethernet. Straps to enable Fiber Ethernet. Connect to
DP83867 RGMII EVM or MAC System using
Header/Samtech.
Perform IEEE and UNH compliance testing Use onboard MSP430 to activate test mode
waveforms.
Run EMI/EMC Test on EVM Use internal PRBS and loopback.
Measure Power Dissipation Connect external power supplies.
4 100 M Media Convertor Demonstrate 100 M functionality on EVM Use SFP and RJ45 connector for fiber and copper
ethernet. Straps are used for unmanaged mode and
MDIO for managed mode.
Demonstrate FAR End fault capability
Demonstrate unmanaged mode of Media convertor
5 1000 M Media Convertor Demonstrate 1000 M functionality on EVM Use SFP and RJ45 connector for fiber and copper
ethernet. Straps are used for unmanaged mode and
MDIO for managed mode.
Demonstrate Link Loss Pass Thru Capability
Demonstrate unmanaged mode of Media Convertor
6 RGMII to SGMII bridge Demonstrate SGMII as MAC able to link with SGMII
i/f of Phy ( DP83867)
Connect to DP83867 SGMII EVM over SMA
connectors and monitor RGMII header on 869 EVM.
Demonstrate SGMII link speed is reflected on
RGMII
Demonstrate Complete Data path Use-case Use DP83867 RGMII EVM and SGMII EVM with
DP83869EVM.
7 SGMII to RGMII bridge Demonstrate RGMII of DP83869 is able to link-up
with RGMII of DP83867
Connect to DP83867 RGMII EVM over Samtech
connectors and monitor SGMII SMA on 869 EVM.
Demonstrate SGMII link speed is reflecting RGMII
speed
Demonstrate Complete Data path Use-case Use DP83867 RGMII EVM and SGMII EVM with
DP83869EVM.
