LMK04821 , LMK04826 , LMK04828
SNAS605AR –MARCH 2013–REVISED DECEMBER 2015 www.ti.com
9.7.8.7 PLL2_LF_R4, PLL2_LF_R3
This register controls the integrated loop filter resistors.
Table 71. Register 0x16C
POR
BIT NAME DESCRIPTION
DEFAULT
7:6 NA 0 Reserved
Internal loop filter components are available for PLL2, enabling either 3rd or 4th order loop
filters without requiring external components.
Internal loop filter resistor R4 can be set according to the following table.
Field Value Resistance
0 (0x00) 200 Ω
1 (0x01) 1 kΩ
5:3 PLL2_LF_R4 0
2 (0x02) 2 kΩ
3 (0x03) 4 kΩ
4 (0x04) 16 kΩ
5 (0x05) Reserved
6 (0x06) Reserved
7 (0x07) Reserved
Internal loop filter components are available for PLL2, enabling either 3rd or 4th order loop
filters without requiring external components.
Internal loop filter resistor R3 can be set according to the following table.
Field Value Resistance
0 (0x00) 200 Ω
1 (0x01) 1 kΩ
2:0 PLL2_LF_R3 0
2 (0x02) 2 kΩ
3 (0x03) 4 kΩ
4 (0x04) 16 kΩ
5 (0x05) Reserved
6 (0x06) Reserved
7 (0x07) Reserved
