PCB Layout and Bill of Materials
A.2 Bill of Materials
Table A-1 is the Crypto Connected LaunchPad bill of materials list.
Table A-1. Crypto Connected LaunchPad Bill of Materials
Item Ref Qty Description Mfg Part Number
1 C1 1
Capacitor, 1000 pF, 2kV,
20%, X7R, 1210
Kemet C1210C102MGRACTU
2
C3, C4, C5, C10, C11, C12,
C13, C16, C17, C18, C19,
C21, C22, C23, C24, C25,
C26, C27, C28, C29, C30,
C40, C41, C42, C43, C46
26
Capacitor, 0.1 µF 16 V,
10%, 0402 X7R
Taiyo Yuden EMK105B7104KV-F
3 C31 1
Capacitor, 4700 pF, 2kV,
10%, X7R, 1812
AVX 1812GC472KAT1A
4 C32, C33 2
Capacitor, 3300 pF, 50 V,
10%, X7R, 0603
TDK C1608X7R1H332K
5 C6, C14 2
Capacitor, 1 µF, X5R, 10 V,
low ESR, 0402
Johanson
Dielectrics Inc
100R07X105KV4T
6 C7, C15, C20 3
Capacitor, 2.2 µF, 16 V,
10%, 0603, X5R
Murata GRM188R61C225KE15D
7
C8, C9, C44,
C45, C47, C48
6
Capacitor, 12 pF, 50 V,
5%, 0402, COG
Murata GRM1555C1H120JZ01D
8 D0, D1, D2, D3, D4 5 Green LED 0603 Everlight 19-217/G7C-AL1M2B/3T
9
J1, J2, J3,
J4, J5, J6, J7
7
Jumper, 0.100, Gold,
Black, Open
3M 969102-0000-DA
Kobiconn 151-8000-E
10 JP1 1
Header, 2x3, 0.100, T-hole,
vertical unshrouded,
0.230 mate, gold
FCI 67996-206HLF
11 JP2, JP3 2
Header, 1x2, 0.100, T-hole,
vertical unshrouded, 0.220 mate
3M 961102-6404-AR
FCI 68001-102HLF
Anyone 1x2-head
12 JP4, JP5 2
Header, 2x2, 0.100, T-hole,
vertical unshrouded, 0.230 mate
FCI 67997-104HLF
4UCON 00998
13
R1, R2, R3, R4,
R5, R29, R35, R44
8
Resistor, 10k Ω, 1/10W,
5%, 0402 thick film
Yageo RC0402FR-0710KL
14 R17, R26, R36 3 100k 5% 0402 resistor SMD Rohm MCR01MRTJ104
15 R18, R51 2 Resistor 0402 100 Ω 5% Rohm MCR1MRTJ101
16 R23, R21, R22, R24 4 Resistor 49.9 Ω 0402. 1 % Rohm MCR01MRTF49R9
17 R25 1 Resistor 4.87k 1% 0402 SMD Rohm MCR01MRTF4871
18 R28 1
Resistor, 5.6k Ω,
1/10W, 5%, 0402
Panasonic ERJ-2GEJ562X
19 R32, R43, R45, R46 4 Resistor 75 Ω 0402 5% Rohm MCR01MRTJ750
20 R34, R52 2
Resistor, 1M OH,
1/10W, 5% 0603 SMD
Panasonic ERJ-3GEYJ105V
21 R38 1
Resistor, 51 Ω,
1/10W, 5%, 0402
Panasonic ERJ-2GEJ510X
