30
SPMU372A–September 2015–Revised October 2016
Submit Documentation Feedback
Copyright © 2015–2016, Texas Instruments Incorporated
Schematic
Appendix B
SPMU372A–September 2015–Revised October 2016
Schematic
This section contains the complete schematics for the TM4C Series TM4C129E Crypto Connected
LaunchPad.
• Microcontroller, USB, Buttons, and LED's
• BoosterPack connectors
• Breadboard connector
• Ethernet and Ethernet LED's
• Power
• In-Circuit Debug Interface
