PCB Layout and Bill of Materials
Table A-1. Crypto Connected LaunchPad Bill of Materials (continued)
Item Ref Qty Description Mfg Part Number
PCB Do Not Populate List (Shown for information only)
43 C2 1
Capacitor, 0.1 µF 16 V,
10%, 0402 X7R
Taiyo Yuden EMK105B7104KV-F
44 H1, H4, H6 3
Screw, #4 x 0.625" Pan head,
sheet metal, Phillips/slotted
(for fan)
McMaster 90077A112
45 R12, R13, R14 3
Resistor, 5.6k Ω,
1/10W, 5%, 0402
Panasonic ERJ-2GEJ562X
46 R48 1 Resistor 0402 1% 52.3k Rohm TRR01MZPF5232
47
TP1, TP2, TP3, TP4, TP5,
TP6, TP7, TP8, TP9,
TP10, TP11, TP12, TP13,
TP14, TP15, TP16, TP17
17
Terminal, test point miniature
loop, red, T-hole
Keystone 5000
48 X1 1
Header, 2x7, 0.100, T-hole,
vertical, unshrouded, 0.230
mate
FCI 67997-114HLF
49 X11A 1
Valvano style bread board
connect. Right angle extended,
1 x 49 0.100 pitch.
Samtec TSW-149-09-F-S-RE
50 X11B 1
Valvano style breadboard
header
Samtec TSW-149-08-F-S-RA
To Next Page
